Modular LED Sports Ground Flood lights 800W CE ROHS Listed IP65 / IK08 Protection

Name: Modular LED Sports Ground Flood lights 800W CE ROHS Listed IP65 IK08 Protection
Brand: DUALRAYS
Price: 1 USD

Quality Modular LED Sports Ground Flood lights 800W CE ROHS Listed IP65 / IK08 Protection for sale

Brand Name : DUALRAYS

Model Number : DR-SPL800-FG2

Certification : CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available

Place of Origin : Shenzhen,China

MOQ : 1pcs

Price : negotiable

Delivery Time : 5-15 Bussiness Day

Packaging Details : Netural Package/OEM and ODM Package Available

Payment Terms : L/C, T/T, Western Union

Supply Ability : 50000PCS/Month

Rated Wattage : 800W

CE Certificate : CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available

IP Class : IP66

IK Grade : IK08

Beam : 60°/90° /30°

CCT : 3000-6500K

Contact Now

Modular LED Sports Ground Flood lights 800W CE ROHS Listed

Features:

* Aiming device Laser Pointer;

* 30°/60°/90° beam angle for options;

* 400W 45000lm, for 800W MHL equivalent;
* ±360° adjustable bracket;

* TM21(L80>50000hrs);

Model No.	DR-SPL300-FGXP	DR-SPL400-FGXP	DR-SPL600-FGXP	DR-SPL800-FGXP
System Watts/W	300W	400W	600W	800W
System Efficiency/LPW	150LPW
Lumen Output/lm	45.000±5%	60.000±5%	90.000±5%	120.000±5%
Rated Input Voltage/V	AC100~277V, 50/60Hz
LEDs Light Source	SMD5050
SDCM	<5
CCT/K	5000K for Standard (3000K/4000K/5700K/6500K Optional)
CRI/Ra	>70Ra (>80Ra for Option)
Power Factor	>0.95
THD	<10%
Beam Angle(Optional)	30°/60°/90°
UGR	<25
Surge Protection	4~6KV SPD built in Driver,Exterior SPD 20KV Meanwell Optional
LED Driver	Meanwell ELG / HLG Optional
IP Rating	IP65
Dimming(Optional)	1-10V, DALI,PWM,Zigbee for Option
Safety Protection	Open Circuit / Short Circuit / Over-voltage / Over Temperature Protection
Start Time	0.5s
Protection Class	ClassⅠ
Finishing Color(Optional)	Black RAL9017(Standard) / White RAL9016 Optional
Material	Aluminum+PC
Lifespan/hrs	70.000 Hrs (Ta=30℃@L70)
Operation Temp/℃	40°C to + 50°C(-40°F to 122°F)
Storage Temp/℃	- 40°C to + 65°C(-40°F to 149°F)
Switching Cycles	100,000 Times
Certificate	CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available

Character/Power	300W	400W	600W	800W
A / mm	Ø445	Ø445	Ø537	Ø537
B / mm	321	321	373	373

Modular LED Sports Ground Flood lights 800W CE ROHS Listed IP65 / IK08 Protection

Model No.	Net Weight/Kg	Outer Carton Size/mm	Gross Weight/Kg	QTY”/CTN
DR-SPL300-FGXP	12.4	610510250	13.8	1PCS/CTN
DR-SPL400-FGXP	12.9	610510250	14.7	1PCS/CTN
DR-SPL600-FGXP	25.3	890710275	27.6	1PCS/CTN
DR-SPL800-FGXP	25.9	890710275	28.8	1PCS/CTN

Modular LED Sports Ground Flood lights 800W CE ROHS Listed IP65 / IK08 Protection

In addition,we can provide our customers value added service with Dialux software for lighting design projects free of charge.
Modular LED Sports Ground Flood lights 800W CE ROHS Listed IP65 / IK08 Protection

(DIALUX Simulation)

　　Dualrays adheres to independent innovation, Dualraysers try to build a world well-known LED industrial Lighting Brand.　　
Modular LED Sports Ground Flood lights 800W CE ROHS Listed IP65 / IK08 Protection

(Partnership)
